// Designer : LZB
//
// Description:
// The Module to realize a simple NICE core
//
// ====================================================================
`include "e203_defines.v"
`ifdef E203_HAS_NICE//{
module e203_subsys_nice_core (
// System
input nice_clk ,
input nice_rst_n ,
output nice_active ,
output nice_mem_holdup ,
// output nice_rsp_err_irq ,
// Control cmd_req
input nice_req_valid ,
output nice_req_ready ,
input [`E203_XLEN-1:0] nice_req_inst ,
input [`E203_XLEN-1:0] nice_req_rs1 ,
input [`E203_XLEN-1:0] nice_req_rs2 ,
// Control cmd_rsp
output nice_rsp_valid ,
input nice_rsp_ready ,
output [`E203_XLEN-1:0] nice_rsp_rdat ,//写数据到寄存器
output nice_rsp_err ,
// Memory lsu_req
output nice_icb_cmd_valid ,
input nice_icb_cmd_ready ,
output [`E203_ADDR_SIZE-1:0] nice_icb_cmd_addr ,
output nice_icb_cmd_read ,
output [`E203_XLEN-1:0] nice_icb_cmd_wdata ,//写数据到内存
// output [`E203_XLEN_MW-1:0] nice_icb_cmd_wmask , //
output [1:0] nice_icb_cmd_size ,
// Memory lsu_rsp
input nice_icb_rsp_valid ,
output nice_icb_rsp_ready ,
input [`E203_XLEN-1:0] nice_icb_rsp_rdata ,
input nice_icb_rsp_err
);
localparam ROWBUF_DP = 4;
localparam ROWBUF_IDX_W = 2;
localparam ROW_IDX_W = 2;
localparam COL_IDX_W = 4;
localparam PIPE_NUM = 3;
// here we only use custom3:
// CUSTOM0 = 7'h0b, R type
// CUSTOM1 = 7'h2b, R tpye
// CUSTOM2 = 7'h5b, R type
// CUSTOM3 = 7'h7b, R type
// RISC-V format
// .insn r 0x33, 0, 0, a0, a1, a2 0: 00c58533[ ]+add [ ]+a0,a1,a2
// .insn i 0x13, 0, a0, a1, 13 4: 00d58513[ ]+addi[ ]+a0,a1,13
// .insn i 0x67, 0, a0, 10(a1) 8: 00a58567[ ]+jalr[ ]+a0,10 (a1)
// .insn s 0x3, 0, a0, 4(a1) c: 00458503[ ]+lb [ ]+a0,4(a1)
// .insn sb 0x63, 0, a0, a1, target 10: feb508e3[ ]+beq [ ]+a0,a1,0 target
// .insn sb 0x23, 0, a0, 4(a1) 14: 00a58223[ ]+sb [ ]+a0,4(a1)
// .insn u 0x37, a0, 0xfff 18: 00fff537[ ]+lui [ ]+a0,0xfff
// .insn uj 0x6f, a0, target 1c: fe5ff56f[ ]+jal [ ]+a0,0 target
// .insn ci 0x1, 0x0, a0, 4 20: 0511 [ ]+addi[ ]+a0,a0,4
// .insn cr 0x2, 0x8, a0, a1 22: 852e [ ]+mv [ ]+a0,a1
// .insn ciw 0x0, 0x0, a1, 1 24: 002c [ ]+addi[ ]+a1,sp,8
// .insn cb 0x1, 0x6, a1, target 26: dde9 [ ]+beqz[ ]+a1,0 target
// .insn cj 0x1, 0x5, target 28: bfe1 [ ]+j [ ]+0 targe
////////////////////////////////////////////////////////////
// decode
////////////////////////////////////////////////////////////
wire [6:0] opcode = {7{nice_req_valid}} & nice_req_inst[6:0];//提取opcode
wire [2:0] rv32_func3 = {3{nice_req_valid}} & nice_req_inst[14:12];//提取func3
wire [6:0] rv32_func7 = {7{nice_req_valid}} & nice_req_inst[31:25];//提取func7
// wire opcode_custom0 = (opcode == 7'b0001011);
// wire opcode_custom1 = (opcode == 7'b0101011);
// wire opcode_custom2 = (opcode == 7'b1011011);
wire opcode_custom3 = (opcode == 7'b1111011); //匹配opcode确认为custom3自定义指令
wire rv32_func3_000 = (rv32_func3 == 3'b000); //匹配func3
wire rv32_func3_001 = (rv32_func3 == 3'b001);
wire rv32_func3_010 = (rv32_func3 == 3'b010);
wire rv32_func3_011 = (rv32_func3 == 3'b011);
wire rv32_func3_100 = (rv32_func3 == 3'b100);
wire rv32_func3_101 = (rv32_func3 == 3'b101);
wire rv32_func3_110 = (rv32_func3 == 3'b110);
wire rv32_func3_111 = (rv32_func3 == 3'b111);
wire rv32_func7_0000000 = (rv32_func7 == 7'b0000000); //匹配func7
wire rv32_func7_0000001 = (rv32_func7 == 7'b0000001);
wire rv32_func7_0000010 = (rv32_func7 == 7'b0000010);
wire rv32_func7_0000011 = (rv32_func7 == 7'b0000011);
wire rv32_func7_0000100 = (rv32_func7 == 7'b0000100);
wire rv32_func7_0000101 = (rv32_func7 == 7'b0000101);
wire rv32_func7_0000110 = (rv32_func7 == 7'b0000110);
wire rv32_func7_0000111 = (rv32_func7 == 7'b0000111);
////////////////////////////////////////////////////////////
// custom3:
// Supported format: only R type here
// Supported instr:
// 1. custom3 lbuf: load data(in memory) to row_buf
// lbuf (a1)
// .insn r opcode, func3, func7, rd, rs1, rs2
// 2. custom3 sbuf: store data(in row_buf) to memory
// sbuf (a1)
// .insn r opcode, func3, func7, rd, rs1, rs2
// 3. custom3 acc rowsum: load data from memory(@a1), accumulate row datas and write back
// rowsum rd, a1, x0
// .insn r opcode, func3, func7, rd, rs1, rs2
////////////////////////////////////////////////////////////
wire custom3_lbuf = opcode_custom3 & rv32_func3_010 & rv32_func7_0000001; //判断是否是custom3_lbuf指令
wire custom3_sbuf = opcode_custom3 & rv32_func3_010 & rv32_func7_0000010;
wire custom3_rowsum = opcode_custom3 & rv32_func3_110 & rv32_func7_0000110;
////////////////////////////////////////////////////////////
// multi-cyc op
////////////////////////////////////////////////////////////
wire custom_multi_cyc_op = custom3_lbuf | custom3_sbuf | custom3_rowsum;//判断是否是协处理器指令
// need access memory
wire custom_mem_op = custom3_lbuf | custom3_sbuf | custom3_rowsum;//判断是否需要访问内存
////////////////////////////////////////////////////////////
// NICE FSM
////////////////////////////////////////////////////////////
parameter NICE_FSM_WIDTH = 2; //D触发器重载参数（DW）
parameter IDLE = 2'd0; //IDLE状态
parameter LBUF = 2'd1; //LBUF状态
parameter SBUF = 2'd2; //SBUF状态
parameter ROWSUM = 2'd3; //ROWSUM状态
wire [NICE_FSM_WIDTH-1:0] state_r; //D触发器的输出状态（当前状态）
wire [NICE_FSM_WIDTH-1:0] nxt_state; //D触发器的输入状态（下一状态）
wire [NICE_FSM_WIDTH-1:0] state_idle_nxt; //IDLE状态的下一状态
wire [NICE_FSM_WIDTH-1:0] state_lbuf_nxt; //LBUF状态的下一状态
wire [NICE_FSM_WIDTH-1:0] state_sbuf_nxt; //SBUF状态的下一状态
wire [NICE_FSM_WIDTH-1:0] state_rowsum_nxt; //ROWSUM状态的下一状态
wire nice_req_hsked;//与cpu握手成功，已接收指令
wire nice_rsp_hsked;//与cpu握手成功，已发送结果
wire nice_icb_rsp_hsked;//与memory握手成功，已接收反馈
wire illgel_instr = ~(custom_multi_cyc_op);//0：代表是协处理器指令 1：代表非协处理器指令
wire state_idle_exit_ena; //退出IDLE状态使能信号
wire state_lbuf_exit_ena; //退出LBUF状态使能信号
wire state_sbuf_exit_ena; //退出SBUF状态使能信号
wire state_rowsum_exit_ena; //退出ROWSUM状态使能信号
wire state_ena; //D触发器的状态使能输入
wire state_is_idle = (state_r == IDLE); //当前状态是IDLE状态
wire state_is_lbuf = (state_r == LBUF); //当前状态是LBUF状态
wire state_is_sbuf = (state_r == SBUF); //当前状态是SBUF状态
wire state_is_rowsum = (state_r == ROWSUM); //当前状态是ROWSUM状态
//如果当前状态是IDLE状态，与cpu握手成功，已接收指令，是协处理器指令，则使能退出IDLE状态使能信号
assign state_idle_exit_ena = state_is_idle & nice_req_hsked & ~illgel_instr;
//IDLE状态的下一状态是LBUF或SBUF或ROWSUM
assign state_idle_nxt = custom3_lbuf ? LBUF :
custom3_sbuf ? SBUF :
custom3_rowsum ? ROWSUM :
IDLE;
wire lbuf_icb_rsp_hsked_last; //LBUF指令操作结束信号
//如果当前状态是LBUF状态，LBUF指令操作结束信号为1,则使能退出LBUF状态使能信号
assign state_lbuf_exit_ena = state_is_lbuf & lbuf_icb_rsp_hsked_last;
//LBUF状态的下一状态是IDLE状态
assign state_lbuf_nxt = IDLE;
wire sbuf_icb_rsp_hsked_last; //SBUF指令操作结束信号
//如果当前状态是SBUF状态，SBUF指令操作结束信号为1,则使能退出SBUF状态使能信号
assign state_sbuf_exit_ena = state_is_sbuf & sbuf_icb_rsp_hsked_last;
//SBUF状态的下一状态是IDLE状态
assign state_sbuf_nxt = IDLE;
wire rowsum_done; //ROWSUM指令操作结束信号
//如果当前状态是ROWSUM状态，ROWSUM指令操作结束信号为1,则使能退出ROWSUM状态使能信号
assign state_rowsum_exit_ena = state_is_rowsum & rowsum_done;
//ROWSUM状态的下一状态是IDLE状态
assign state_rowsum_nxt = IDLE;
//D触发器的输入状态（下一状态）由退出的指令以及退出指令指定的下一状态确定
assign nxt_state = ({NICE_FSM_WIDTH{state_idle_exit_ena }} & state_idle_nxt )
| ({NICE_FSM_WIDTH{state_lbuf_exit_ena }} & state_lbuf_nxt )
| ({NICE_FSM_WIDTH{state_sbuf_exit_ena }} & state_sbuf_nxt )
| ({NICE_FSM_WIDTH{state_rowsum_exit_ena }} & state_rowsum_nxt )
;
//D触发器的状态使能输入由是否有指令退出使能
assign state_ena = state_idle_exit_ena | state_lbuf_exit_ena
| state_sbuf_exit_ena | state_rowsum_exit_ena;
//例化D触发器，重载参数DW，初始化状态为IDLE，当state_ena为1时，打一拍，nxt_state赋值给state_r，低电平复位（sirv_gnrl_dffs.v）
sirv_gnrl_dfflr #(NICE_FSM_WIDTH) state_dfflr (state_ena, nxt_state, state_r, nice_clk, nice_rst_n);
////////////////////////////////////////////////////////////
// instr EXU
////////////////////////////////////////////////////////////
wire [ROW_IDX_W-1:0] clonum = 2'b10; // fixed clonum 计数到2
//wire [COL_IDX_W-1:0] rownum;
//////////// 1. custom3_lbuf
wire [ROWBUF_IDX_W-1:0] lbuf_cnt_r; //D触发器的输出当前计数值
wire [ROWBUF_IDX_W-1:0] lbuf_cnt_nxt; //D触发器的输入下一计数值
wire lbuf_cnt_clr;//清零
wire lbuf_cnt_incr;//计数
wire lbuf_cnt_ena;//D触发器的输入计数使能
wire lbuf_cnt_last;//计到最后一个数
wire lbuf_icb_rsp_hsked;//IBUF状态下与memory握手成功，已接收反馈信号
wire nice_rsp_valid_lbuf;//IBUF状态的反馈cpu请求信号
wire nice_icb_cmd_valid_lbuf;//IBUF状态的读写memory请求信号
//LBUF状态下，与memory握手成功，已接收反馈，使能IBUF状态下与memory握手成功，已接收反馈信号
assign lbuf_icb_rsp_hsked = state_is_lbuf & nice_icb_rsp_hsked;
//计到最后一个数，IBUF状态下与memory握手成功，已接收反馈，使能LBUF指令操作结束信号，last, wait lbuf_cnt_last
assign lbuf_icb_rsp_hsked_last = lbuf_icb_rsp_hsked & lbuf_cnt_last;
//D触发器的输出当前计数值=2,则计到最后一个数
assign lbuf_cnt_last = (lbuf_cnt_r == clonum);
//与cpu握手成功，接收指令，指令是custom3_lbuf，则清零,first
assign lbuf_cnt_clr = custom3_lbuf & nice_req_hsked;
//IBUF状态下与memory握手成功，已接收反馈，但未计到最后一个数，则一直计数
assign lbuf_cnt_incr = lbuf_icb_rsp_hsked & ~lbuf_cnt_last;
//D触发器的输入计数使能由清零信号和计数信号确定
assign lbuf_cnt_ena = lbuf_cnt_clr | lbuf_cnt_incr;
//D触发器的输入下一计数值由清零信号和计数信号确定
assign lbuf_cnt_nxt = ({ROWBUF_IDX_W{lbuf_cnt_clr }} & {ROWBUF_IDX_W{1'b0}})
| ({ROWBUF_IDX_W{lbuf_cnt_incr}} & (lbuf_cnt_r + 1'b1) )
;
//例化D触发器，重载参数DW，初始化数为0，当lbuf_cnt_ena为1时，打一拍，lbuf_cnt_nxt赋值给lbuf_cnt_r，低电平复位（sirv_gnrl_dffs.v）
sirv_gnrl_dfflr #(ROWBUF_IDX_W) lbuf_cnt_dfflr (lbuf_cnt_ena, lbuf_cnt_nxt, lbuf_cnt_r, nice_clk, nice_rst_n);
// nice_rsp_valid wait for nice_icb_rsp_valid in LBUF
//LBUF状态下，与memory握手成功，已接收反馈，且计到最后一个数，则使能IBUF状态的反馈cpu请求信号,last, wait lbuf_cnt_last
assign nice_rsp_valid_lbuf = state_is_lbuf & lbuf_cnt_last & nice_icb_rsp_valid;
// nice_icb_cmd_valid sets when lbuf_cnt_r is not full in LBUF
//LBUF状态下，D触发器的输出当前计数值小于最大值，则使能IBUF状态的读写memory请求信号,first
assign nice_icb_cmd_valid_lbuf = (state_is_lbuf & (lbuf_cnt_r < clonum));
//////////// 2. custom3_sbuf
wire [ROWBUF_IDX_W-1:0] sbuf_cnt_r; //D触发器的输出当前计数值
wire [ROWBUF_IDX_W-1:0] sbuf_cnt_nxt; //D触发器的输入下一计数值
wire sbuf_cnt_clr;//清零
wire sbuf_cnt_incr;//计数
wire sbuf_cnt_ena;//D触发器的输入计数使能
wire sbuf_cnt_last;//计到最后一个数
wire sbuf_icb_cmd_hsked;//SBUF状态下与memory握手成功，已发送读写地址和数据信号
wire sbuf_icb_rsp_hsked;//SBUF状态下与memory握手成功，已接收反馈信号
wire nice_rsp_valid_sbuf;//SBUF状态的反馈cpu请求信号
wire nice_icb_cmd_valid_sbuf;//SBUF状态的读写memory请求信号
wire nice_icb_cmd_hsked;//与memory握手成功，已发送读写地址和数据
//SBUF状态下，与memory握手成功，已发送读写地址和数据，则使能SBUF状态下与memory握手成功，已发送读写地址和数据信号，second，第一个计数器开启
assign sbuf_icb_cmd_hsked = (state_is_sbuf | (state_is_idle & custom3_sbuf)) & nice_icb_cmd_hsked;
//SBUF状态下，与memory握手成功，已接收反馈，使能SBUF状态下与memory握手成功，已接收反馈信号，third，第二个计数器开启
assign sbuf_icb_rsp_hsked = state_is_sbuf & nice_icb_rsp_hsked;
//计到最后一个数，SBUF状态下与memory握手成功，已接收反馈，使能SBUF指令操作结束信号, last, wait sbuf_cnt_last
assign sbuf_icb_rsp_hsked_last = sbuf_icb_rsp_hsked & sbuf_cnt_last;
//D触发器的输出当前计数值=2,则计到最后一个数
assign sbuf_cnt_last = (sbuf_cnt_r == clonum);
//assign sbuf_cnt_clr = custom3_sbuf & nice_req_hsked;
//SBUF指令操作结束，则清零，last, wait sbuf_cnt_last
assign sbuf_cnt_clr = sbuf_icb_rsp_hsked_last;
//SBUF状态下与memory握手成功，已接收反馈，但未计到最后一个数，则一直计数
assign sbuf_cnt_incr = sbuf_icb_rsp_hsked & ~sbuf_cnt_last;
//D触发器的输入计数使能由清零信号和计数信号确定
assign sbuf_cnt_ena = sbuf_cnt_clr | sbuf_cnt_incr;
//D触发器的输入下一计数值由清零信号和计数信号确定
assign sbuf_cnt_nxt = ({ROWBUF_IDX_W{sbuf_cnt_clr }} & {ROWBUF_IDX_W{1'b0}})
| ({ROWBUF_IDX_W{sbuf_cnt_incr}} & (sbuf_cnt_r + 1'b1) )
;
//例化D触发器，重载参数DW，初始化数为0，当sbuf_cnt_ena为1时，打一拍，sbuf_cnt_nxt赋值给sbuf_cnt_r，低电平复位（sirv_gnrl_dffs.v）
sirv_gnrl_dfflr #(ROWBUF_IDX_W) sbuf_cnt_dfflr (sbuf_cnt_ena, sbuf_cnt_nxt, sbuf_cnt_r, nice_clk, nice_rst_n);
// nice_rsp_valid wait for nice_icb_rsp_valid in SBUF
//SBUF状态下，与memory握手成功，已接收反馈，且计到最后一个数，则使能SBUF状态的反馈cpu请求信号,last, wait sbuf_cnt_last
assign nice_rsp_valid_sbuf = state_is_sbuf & sbuf_cnt_last & nice_icb_rsp_valid;
wire [ROWBUF_IDX_W-1:0] sbuf_cmd_cnt_r; //D触发器的输出当前计数值
wire [ROWBUF_IDX_W-1:0] sbuf_cmd_cnt_nxt; //D触发器的输入下一计数值
wire sbuf_cmd_cnt_clr;//清零
wire sbuf_cmd_cnt_incr;//计数
wire sbuf_cmd_cnt_ena;//D触发器的输入计数使能
wire sbuf_cmd_cnt_last;//计到最后一个数
//D触发器的输出当前计数值=2,则计到最后一个数
assign sbuf_cmd_cnt_last = (sbuf_cmd_cnt_r == clonum);
//SBUF指令操作结束，则清零，last, wait sbuf_cnt_last
assign sbuf_cmd_cnt_clr = sbuf_icb_rsp_hsked_last;
//SBUF状态下与memory握手成功，已发送读写地址和数据信号，但未计到最后一个数，则一直计数
assign sbuf_cmd_cnt_incr = sbuf_icb_cmd_hsked & ~sbuf_cmd_cnt_last;
//D触发器的输入计数使能由清零信号和计数信号确定
assign sbuf_cmd_cnt_ena = sbuf_cmd_cnt_clr | sbuf_cmd_cnt_incr;
//D触发器的输入下一计数值由清零信号和计数信号确定
assign sbuf_cmd_cnt_nxt = ({ROWBUF_IDX_W{sbuf_cmd_cnt_clr }} & {ROWBUF_IDX_W{1'b0}})
| ({ROWBUF_IDX_W{sbuf_cmd_cnt_incr}} & (sbuf_cmd_cnt_r + 1'b1) )
;
//例化D触发器，重载参数DW，初始化数为0，当sbuf_cmd_cnt_ena为1时，打一拍，sbuf_cmd_cnt_nxt赋值给sbuf_cmd_cnt_r，低电平复位（sirv_gnrl_dffs.v）
sirv_gnrl_dfflr #(ROWBUF_IDX_W) sbuf_cmd_cnt_dfflr (sbuf_cmd_cnt_ena, sbuf_cmd_cnt_nxt, sbuf_cmd_cnt_r, nice_clk, nice_rst_n);
// nice_icb_cmd_valid sets when sbuf_cmd_cnt_r is not full in SBUF
//SBUF状态下，D触发器的输出当前计数值sbuf_cmd_cnt_r小于等于最大值，sbuf_cnt_r不等于最大值，则使能SBUF状态的读写memory请求信号,first，also last, wait sbuf_cnt_last
assign nice_icb_cmd_valid_sbuf = (state_is_sbuf & (sbuf_cmd_cnt_r <= clonum) & (sbuf_cnt_r != clonum));
//////////// 3. custom3_rowsum
// rowbuf counter 跟前面一样，可以看成是ROWSUM状态下的第一个计数器
wire [ROWBUF_IDX_W-1:0] rowbuf_cnt_r; //D触发器的输出当前计数值
wire [ROWBUF_IDX_W-1:0] rowbuf_cnt_nxt; //D触发器的输入下一计数值
wire rowbuf_cnt_clr;//清零
wire rowbuf_cnt_incr;//计数
wire rowbuf_cnt_ena;//D触发器的输入计数使能
wire rowbuf_cnt_last;//计到最后一个数
wire rowbuf_icb_rsp_hsked;//ROWSUM状态下与memory握手成功，已接收反馈信号
wire rowbuf_rsp_hsked;//ROWSUM状态下与cpu握手成功，已发送结果信号
wire nice_rsp_valid_rowsum;//ROWSUM状态下的反馈cpu请求信号
//ROWSUM状态下的反馈cpu请求，cpu接收反馈，则使能ROWSUM状态下与cpu握手成功，已发送结果信号，last
assign rowbuf_rsp_hsked = nice_rsp_valid_rowsum & nice_rsp_ready;
//ROWSUM状态下，与memory握手成功，已接收反馈，使能ROWSUM状态下与memory握手成功，已接收反馈信号
assign rowbuf_icb_rsp_hsked = state_is_rowsum & nice_icb_rsp_hsked;
//D触发器的输出当前计数值=2,则计到最后一个数
assign rowbuf_cnt_last = (rowbuf_cnt_r == clonum);
//计到最后一个数，且ROWSUM状态下与memory握手成功，已接收反馈信号，则清零
assign rowbuf_cnt_clr = rowbuf_icb_rsp_hsked & rowbuf_cnt_last;
//ROWSUM状态下与memory握手成功，已接收反馈信号，但未计到最后一个数，则一直计数
assign rowbuf_cnt_incr = rowbuf_icb_rsp_hsked & ~rowbuf_cnt_last;
//D触发器的输入计数使能由清零信号和计数信号确定
assign rowbuf_cnt_ena = rowbuf_cnt_clr | rowbuf_cnt_incr;
//D触发器的输入下一计数值由清零信号和计数信号确定
assign rowbuf_cnt_nxt = ({ROWBUF_IDX_W{rowbuf_cnt_clr }} & {ROWBUF_IDX_W{1'b0}})
| ({ROWBUF_IDX_W{rowbuf_cnt_incr}} & (rowbuf_cnt_r + 1'b1))
;
//assign nice_icb_cmd_valid_rowbuf = (state_is_idle & custom3_rowsum)
// | (state_is_rowsum & (rowbuf_cnt_r <= clonum) & (clonum != 0))
// ;
//重载2,使能rowbuf_cnt_ena，打一拍，rowbuf_cnt_nxt赋值给rowbuf_cnt_r
sirv_gnrl_dfflr #(ROWBUF_IDX_W) rowbuf_cnt_dfflr (rowbuf_cnt_ena, rowbuf_cnt_nxt, rowbuf_cnt_r, nice_clk, nice_rst_n);
// recieve data buffer, to make sure rowsum ops come from registers
wire rcv_data_buf_ena;
wire rcv_data_buf_set;//ROWSUM状态下memory请求与反馈结束信号
wire rcv_data_buf_clr;//ROWSUM状态下cpu请求与反馈结束信号
wire rcv_data_buf_valid;
wire [`E203_XLEN-1:0] rcv_data_buf; //从memory读回的操作数
wire [ROWBUF_IDX_W-1:0] rcv_data_buf_idx;
wire [ROWBUF_IDX_W-1:0] rcv_data_buf_idx_nxt;
assign rcv_data_buf_set = rowbuf_icb_rsp_hsked;
assign rcv_data_buf_clr = rowbuf_rsp_hsked;
assign rcv_data_buf_ena = rcv_data_buf_clr | rcv_data_buf_set;
//ROWSUM状态下memory请求与反馈结束，cpu请求与反馈未结束，则rcv_data_buf_idx_nxt等于rowbuf_cnt_r
assign rcv_data_buf_idx_nxt = ({ROWBUF_IDX_W{rcv_data_buf_clr}} & {ROWBUF_IDX_W{1'b0}})
| ({ROWBUF_IDX_W{rcv_data_buf_set}} & rowbuf_cnt_r );
//重载1,使能1,打一拍，rcv_data_buf_ena赋值给rcv_data_buf_valid
sirv_gnrl_dfflr #(1) rcv_data_buf_valid_dfflr (1'b1, rcv_data_buf_ena, rcv_data_buf_valid, nice_clk, nice_rst_n);
//重载32,使能rcv_data_buf_ena，打一拍，nice_icb_rsp_rdata赋值给rcv_data_buf
sirv_gnrl_dfflr #(`E203_XLEN) rcv_data_buf_dfflr (rcv_data_buf_ena, nice_icb_rsp_rdata, rcv_data_buf, nice_clk, nice_rst_n);
//重载2,使能rcv_data_buf_ena，打一拍，rcv_data_buf_idx_nxt赋值给rcv_data_buf_idx
sirv_gnrl_dfflr #(ROWBUF_IDX_W) rowbuf_cnt_d_dfflr (rcv_data_buf_ena, rcv_data_buf_idx_nxt, rcv_data_buf_idx, nice_clk, nice_rst_n);
// rowsum accumulator
wire [`E203_XLEN-1:0] rowsum_acc_r;//当前操作数
wire [`E203_XLEN-1:0] rowsum_acc_nxt;//下一操作数
wire [`E203_XLEN-1:0] rowsum_acc_adder;//操作数和
wire rowsum_acc_ena;
wire rowsum_acc_set;//第一个操作数状态使能
wire rowsum_acc_flg;//非第一个操作数状态使能
wire nice_icb_cmd_valid_rowsum;
wire [`E203_XLEN-1:0] rowsum_res;//操作数总和
assign rowsum_acc_set = rcv_data_buf_valid & (rcv_data_buf_idx == {ROWBUF_IDX_W{1'b0}});
assign rowsum_acc_flg = rcv_data_buf_valid & (rcv_data_buf_idx != {ROWBUF_IDX_W{1'b0}});
//将从memory读回的操作数与当前操作数相加
assign rowsum_acc_adder = rcv_data_buf + rowsum_acc_r;
assign rowsum_acc_ena = rowsum_acc_set | rowsum_acc_flg;
//如果是第一个操作数，则rowsum_acc_nxt等于从memory读回的操作数，否则则等于目前的操作数和
assign rowsum_acc_nxt = ({`E203_XLEN{rowsum_acc_set}} & rcv_data_buf)
| ({`E203_XLEN{rowsum_acc_flg}} & rowsum_acc_adder)
;
//重载32,使能rowsum_acc_ena，打一拍，rowsum_acc_nxt赋值给rowsum_acc_r
sirv_gnrl_dfflr #(`E203_XLEN) rowsum_acc_dfflr (rowsum_acc_ena, rowsum_acc_nxt, rowsum_acc_r, nice_clk, nice_rst_n);
assign rowsum_done = state_is_rowsum & nice_rsp_hsked;//ROWSUM指令操作结束
assign rowsum_res = rowsum_acc_r;//操作数总和
// rowsum finishes when the last acc data is added to rowsum_acc_r
//操作完，nice_rsp_valid_rowsum打开准备反馈给cpu
assign nice_rsp_valid_rowsum = state_is_rowsum & (rcv_data_buf_idx == clonum) & ~rowsum_acc_flg;
// nice_icb_cmd_valid sets when rcv_data_buf_idx is not full in LBUF
//还没从内存取完数，nice_icb_cmd_valid_rowsum一直打开
assign nice_icb_cmd_valid_rowsum = state_is_rowsum & (rcv_data_buf_idx < clonum) & ~rowsum_acc_flg;
//////////// rowbuf //lbuf和rowsum写rowbuf，sbuf读rowbuf，rowsum写入rowbuf的是列加运算的结果
// rowbuf access list:
// 1. lbuf will write to rowbuf, write data comes from memory, data length is defined by clonum
// 2. sbuf will read from rowbuf, and store it to memory, data length is defined by clonum
// 3. rowsum will accumulate data, and store to rowbuf, data length is defined by clonum
wire [`E203_XLEN-1:0] rowbuf_r [ROWBUF_DP-1:0];//16个32位宽的读数据[31:0][3:0]
wire [`E203_XLEN-1:0] rowbuf_wdat [ROWBUF_DP-1:0];//16个32位宽的写数据
wire [ROWBUF_DP-1:0] rowbuf_we;//4位宽的数据,D触发器的使能信号
wire [ROWBUF_IDX_W-1:0] rowbuf_idx_mux; //2位宽的数据
wire [`E203_XLEN-1:0] rowbuf_wdat_mux; //32位宽的数据
wire rowbuf_wr_mux;
//wire [ROWBUF_IDX_W-1:0] sbuf_idx;
// lbuf write to rowbuf
wire [ROWBUF_IDX_W-1:0] lbuf_idx = lbuf_cnt_r; //写入rowbuf的序号
wire lbuf_wr = lbuf_icb_rsp_hsked; //使能lbuf写rowbuf信号
wire [`E203_XLEN-1:0] lbuf_wdata = nice_icb_rsp_rdata;
// rowsum write to rowbuf(column accumulated data)
wire [ROWBUF_IDX_W-1:0] rowsum_idx = rcv_data_buf_idx; //写入rowbuf的序号
wire rowsum_wr = rcv_data_buf_valid; //使能rowsum写rowbuf信号
wire [`E203_XLEN-1:0] rowsum_wdata = rowbuf_r[rowsum_idx] + rcv_data_buf;//列加运算，每行元素分三个D触发器储存
// rowbuf write mux
//选择写入的数据
assign rowbuf_wdat_mux = ({`E203_XLEN{lbuf_wr }} & lbuf_wdata )
| ({`E203_XLEN{rowsum_wr}} & rowsum_wdata)
;
//选择写入的指令信号
assign rowbuf_wr_mux = lbuf_wr | rowsum_wr;
//选择写入rowbuf的序号
assign rowbuf_idx_mux = ({ROWBUF_IDX_W{lbuf_wr }} & lbuf_idx )
| ({ROWBUF_IDX_W{rowsum_wr}} & rowsum_idx)
;
// rowbuf inst //实例化4个D触发器作为rowbuf
genvar i;
generate
for (i=0; i1) begin:gen_rowbuf
//确定写入的序号和使能信号
assign rowbuf_we[i] = (rowbuf_wr_mux & (rowbuf_idx_mux == i[ROWBUF_IDX_W-1:0]))
;
//确定写入的数据
assign rowbuf_wdat[i] = ({`E203_XLEN{rowbuf_we[i]}} & rowbuf_wdat_mux )
;
//生成触发器，并把数据写入，重载32,使能rowbuf_we[i]，打一拍，rowbuf_wdat[i]赋值给rowbuf_r[i]
sirv_gnrl_dfflr #(`E203_XLEN) rowbuf_dfflr (rowbuf_we[i], rowbuf_wdat[i], rowbuf_r[i], nice_clk, nice_rst_n);
end
endgenerate
//////////// mem aacess addr management
wire [`E203_XLEN-1:0] maddr_acc_r;
assign nice_icb_cmd_hsked = nice_icb_cmd_valid & nice_icb_cmd_ready; //与memory握手成功，已发送读写地址和数据
// custom3_lbuf
//wire [`E203_XLEN-1:0] lbuf_maddr = state_is_idle ? nice_req_rs1 : maddr_acc_r ;
//LBUF状态下，操作memory使能信号
wire lbuf_maddr_ena = (state_is_idle & custom3_lbuf & nice_icb_cmd_hsked)
| (state_is_lbuf & nice_icb_cmd_hsked)
;
// custom3_sbuf
//wire [`E203_XLEN-1:0] sbuf_maddr = state_is_idle ? nice_req_rs1 : maddr_acc_r ;
//SBUF状态下，操作memory使能信号
wire sbuf_maddr_ena = (state_is_idle & custom3_sbuf & nice_icb_cmd_hsked)
| (state_is_sbuf & nice_icb_cmd_hsked)
;
// custom3_rowsum
//wire [`E203_XLEN-1:0] rowsum_maddr = state_is_idle ? nice_req_rs1 : maddr_acc_r ;
//ROWSUM状态下，操作memory使能信号
wire rowsum_maddr_ena = (state_is_idle & custom3_rowsum & nice_icb_cmd_hsked)
| (state_is_rowsum & nice_icb_cmd_hsked)
;
// maddr acc
//wire maddr_incr = lbuf_maddr_ena | sbuf_maddr_ena | rowsum_maddr_ena | rbuf_maddr_ena;
wire maddr_ena = lbuf_maddr_ena | sbuf_maddr_ena | rowsum_maddr_ena;
wire maddr_ena_idle = maddr_ena & state_is_idle;//当状态为IDLE时先取出第一个内存地址，即从指令读取的内存地址
//nice_req_rs1是从指令读取的内存地址，之后从memory每取一个数，内存地址要加4,因为每一个数是32位，32/8=4
wire [`E203_XLEN-1:0] maddr_acc_op1 = maddr_ena_idle ? nice_req_rs1 : maddr_acc_r; // not reused
wire [`E203_XLEN-1:0] maddr_acc_op2 = maddr_ena_idle ? `E203_XLEN'h4 : `E203_XLEN'h4;
wire [`E203_XLEN-1:0] maddr_acc_next = maddr_acc_op1 + maddr_acc_op2;
wire maddr_acc_ena = maddr_ena;
//重载32,使能maddr_acc_ena，打一拍，maddr_acc_next赋值给maddr_acc_r
sirv_gnrl_dfflr #(`E203_XLEN) maddr_acc_dfflr (maddr_acc_ena, maddr_acc_next, maddr_acc_r, nice_clk, nice_rst_n);
////////////////////////////////////////////////////////////
// Control cmd_req
////////////////////////////////////////////////////////////
assign nice_req_hsked = nice_req_valid & nice_req_ready;
assign nice_req_ready = state_is_idle & (custom_mem_op ? nice_icb_cmd_ready : 1'b1);
////////////////////////////////////////////////////////////
// Control cmd_rsp
////////////////////////////////////////////////////////////
assign nice_rsp_hsked = nice_rsp_valid & nice_rsp_ready;
assign nice_icb_rsp_hsked = nice_icb_rsp_valid & nice_icb_rsp_ready;
assign nice_rsp_valid = nice_rsp_valid_rowsum | nice_rsp_valid_sbuf | nice_rsp_valid_lbuf;
assign nice_rsp_rdat = {`E203_XLEN{state_is_rowsum}} & rowsum_res;
// memory access bus error
//assign nice_rsp_err_irq = (nice_icb_rsp_hsked & nice_icb_rsp_err)
// | (nice_req_hsked & illgel_instr)
// ;
assign nice_rsp_err = (nice_icb_rsp_hsked & nice_icb_rsp_err);//与memory握手成功，并从memory接收的反馈即为给cpu的反馈
////////////////////////////////////////////////////////////
// Memory lsu
////////////////////////////////////////////////////////////
// memory access list:
// 1. In IDLE, custom_mem_op will access memory(lbuf/sbuf/rowsum)
// 2. In LBUF, it will read from memory as long as lbuf_cnt_r is not full
// 3. In SBUF, it will write to memory as long as sbuf_cnt_r is not full
// 3. In ROWSUM, it will read from memory as long as rowsum_cnt_r is not full
//assign nice_icb_rsp_ready = state_is_ldst_rsp & nice_rsp_ready;
// rsp always ready
assign nice_icb_rsp_ready = 1'b1; //时刻准备接收memory反馈
wire [ROWBUF_IDX_W-1:0] sbuf_idx = sbuf_cmd_cnt_r;
//使能memory请求信号
assign nice_icb_cmd_valid = (state_is_idle & nice_req_valid & custom_mem_op)
| nice_icb_cmd_valid_lbuf
| nice_icb_cmd_valid_sbuf
| nice_icb_cmd_valid_rowsum
;
//（状态idle且命令有效）为寄存器1，否则为maddr_acc_r
assign nice_icb_cmd_addr = (state_is_idle & custom_mem_op) ? nice_req_rs1 :
maddr_acc_r;
//（状态idle且为lbuf或rowsumz指令，为1，为sbuf指令，为0），或者为sbuf状态为0，否则为1，0为写，1为读
assign nice_icb_cmd_read = (state_is_idle & custom_mem_op) ? (custom3_lbuf | custom3_rowsum) :
state_is_sbuf ? 1'b0 :
1'b1;
//（状态idle，sbuf指令）或subf状态，为rowbuf_r[sbuf_idx]，否则为0
assign nice_icb_cmd_wdata = (state_is_idle & custom3_sbuf) ? rowbuf_r[sbuf_idx] :
state_is_sbuf ? rowbuf_r[sbuf_idx] :
`E203_XLEN'b0;
//assign nice_icb_cmd_wmask = {`sirv_XLEN_MW{custom3_sbuf}} & 4'b1111;
assign nice_icb_cmd_size = 2'b10;//2: 代表4字节32位数据
assign nice_mem_holdup = state_is_lbuf | state_is_sbuf | state_is_rowsum; //独占内存信号
////////////////////////////////////////////////////////////
// nice_active
////////////////////////////////////////////////////////////
assign nice_active = state_is_idle ? nice_req_valid : 1'b1;//nice是否在工作
endmodule
`endif//}
